IPC-HDBW2431R-ZAS-S2-DAHUA-CCTV

หมวดหมู่สินค้า: DAHUA IP
รหัส : IPC-HDBW2431R-ZAS-S2
*ราคานี้ยังไม่รวม Vat 7%
ราคา 0บาท

23 กรกฎาคม 2564

ผู้ชม 483 ผู้ชม

IPC-HDBW2431R-ZAS-S2



Product Detail

    · 4MP, 1/3” CMOS image sensor, low illuminance, high image definition
    · Outputs 4MP (2560 × 1440)@25/30 fps, Max. supports 4MP (2688 × 1520)@20 fps
    · H.265 coding, high compression ration, low bit rate
    · Built-in IR LED, max IR distance: 40 m
    · ROI, SMART H.264/H.265, flexible coding, applicable to various bandwidth and storage environments
    · Rotation mode, WDR, 3D DNR, HLC, BLC, digital watermarking,applicable to various monitoring scenes
    · Intelligent detection: Intrusion, tripwire
    · Abnormality detection: Motion detection, video tempering, no SD card,SD card full, SD card error, network disconnected,       IP conflict, illegal access,voltage detection
    · Alarm: In, out; audio: In, out; max. 256 GB SD card
    · 12V DC/POE power support
    · IP67, IK10 protection grade



รายละเอียด

IPC-HDBW2431R-ZAS-S2


Camera
Image Sensor 1/3” CMOS
Effective Pixels 2688 (H) × 1520 (V)
ROM 128 MB
RAM 128 MB
Scanning System Progressive
Electronic Shutter Speed Auto/Manual 1/3 s–1/100000 s
Min. Illumination 0.01 Lux @ F1.6
IR Distance 40 m (131.23 ft) (IR)
IR On/Off Control Auto/Manual
IR LEDs Number 2 (IR LED)
Pan/Tilt/Rotation Range
Horizonal: 0°–355°
Vertical: 0°–67°
Rotation: 0°–355°



Lens
Lens Type Motorized vari-focal
Mount Type φ14
Focal Length 2.7 mm–13.5 mm
Max. Aperture F1.6
Field of View
Horizonal: 104°–27°
Vertical: 55°–15°
Diagonal: 124°–31°
Optical Zoom 5 times
Iris Type Fixed



Structure
Casing Metal
Dimensions Φ122 mm × 88.9 mm (Φ4.80″ × 3.50″)
Net Weight 0.47 kg (1.04 lb)
Gross Weight 0.63 kg (1.39 lb)



Specification

Download PDF
